Raw material

Post-consumer PE/PP films, bags, fabrics

Final product &

Output capacity

PE, PP scraps/flakes

300kg/h

Machine color

Standard color: （Blue and Yellow）

Description of final product

1. Moisture: max 7-8%

2. Bulk density: 0.1G/CM3

3. Total impurity content:150ppm

4. Particle size: 40-60mm

(can be designed as per special requirement)

Warehouse/Workshop

Construction of foundations, construction works, earthworks, and wall works;

Supply of cranes, fork-lifts or other lifting equipment; Mounting materials and tools;

Dimension (M*M*M): 40m(L)×10m(W)×6m(H);

Power supply

Supply voltage: 3*380V+N+PE;

Voltage tolerance: +5%/-5%;

Control voltage: 24VDC+220VAC;

Frequency: 50HZ+-2%

Wire/cables/water hose:

Wires/cables: from power supply to control cabinet of this production line and all electrical cables from control cabinet to each machine;

Water hose: supply water to machines and pools;

Installation power

171KW (Actual power consumption percentage :80%)

Water supply

3 ton/h（Proposed water-treatment project）

Pressure: 0.4Mpa

Heat supply (steam)

Temperature: 170℃

Output flow: 150kg/h

Pressure: 0.7Mpa

Ancillary staff

4 Persons

Project

300kg/hr PE/PP film washing line

Price

USD58,750 FOB Shanghai INCOTERMS 2000

Payment term

30% as down payment by T/T;

70% by T/T before delivery and after inspection;

Delivery time

80 working days since the date of receiving down payment

Packing

Wood pallet covered by plastic film;

Warranty period

13 months since date of bill of lading

No.

Machine

Photo of machine

Technical specifications

1

Belt conveyor

Waste film feeding

Width of belt: 475mm

Basic material of belt: PVC

Motor power: 1.5kw

2

Crusher

Film crushing

Motor power: 37Kw

Diameter of hole of screen sieve: 40-60mm

Screen sieve replacement: manual

Cover opening: electric

we can design the diameter of hole up to customer’s requirement

Qty. of rotary blades: 6pcs

Qty. of stationary blades: 4pcs

Basic material of blades:

High-quality alloy steel(Cr12MoV)

Rotation speed of blade: 600RPM

3

Frame

4

Floating washer 1

Cleaning film scraps and separating remained dirt and dust

Motor power of thumbwheel:0.75KW

Quantity of thumbwheel: 6sets

Equipped with a impurity-suction pump

Motor power of horizontal screw loader:1.5kw

Tank dimension:4.4m(L)*1.02m(w)*1.2m(H)

Part contact with raw materials: stainless steel

5

Screw loader 1

Scraps conveying to the screw loader 2

Motor power: 3Kw

Dia. of screw: 250mm

Part contact with raw materials: stainless steel

6

Screw loader 2

Scraps conveying into the bottom of hot washer

Motor power: 2.2Kw

Dia. of screw: 250mm

Part contact with raw materials: stainless steel

7

Hot washer

Connected with steam boiler. Steam supplied into washing tank to heat water and scraps. Hot water makes waste loosen. Meanwhile add caustic soda and cleaning chemicals to remove dirt and oil from film.

Motor power: 4Kw

Dimension of hot chamber (Dia.×Height): 1.2M×1.5M

Volume of hot chamber≈1.69 m3

Part contact with raw materials: stainless steel

8

High-speed friction

washer

Get rid of dirty waste and oil

Motor power: 15Kw

Water pump: 1.5Kw (hot water circulation for reuse)

Rotary speed of screw: 1200rpm

Part contact with raw materials: stainless steel

9

Screw loader 3

Scraps conveyed into floating washer 2

Motor power: 2.2Kw

Part contact with raw materials: stainless steel

10

Floating washer 2

Cleaning film scraps and separating remained dirt and dust

Motor power of thumbwheel:0.75KW

Quantity of thumbwheel:6sets

Motor power of horizontal screw loader:1.5kw

Tank dimension: 4.4m (L)*1. 2m(w)*1.6m(H)

Part contact with raw materials: stainless steel

11

Screw loader 4

Scraps conveyed

Motor power: 3Kw

Part contact with raw materials: stainless steel

12

Centrifugal dryer

Dewatering

Main motor power:45Kw

Rotation of screen sieve: electric,

motor power 0.37Kw

Rotary speed of screw: 1500rpm

Part contact with raw materials: stainless steel

13

Pipeline dryer

Hot air drying

Heating power: 48Kw

Blower: 5.5Kw

Length: 10m

14

Storage silo

Storage silo for Scraps

Basic material of storage silo: stainless steel

Dimension of silo: 4M (H)×1M(Dia.)

Part contact with raw materials: stainless steel

Double outlet

15

Electric cabinet

Electric control system for washing line

Touch screen: SIEMENS

PLC control module: Mitsubishi

Electric control component: e.g. Circuit-breaker, AC contact, press button, pilot lamp (Schneider, Siemens, and similar famous brands).

This electric cabinet is used to control all machines in Film washing line.
